Specification

Value

Lifecycle

Active

Distrib. Inventory

No

Generation

12 Gb/s

External Ports

8

External Connectors

2 x4 SFF-8644

Management Software

LSI Storage Authority (LSA), StorCLI (Command-Line Interface), HII (UEFI Human Interface Infrastructure)

Cache Protection

CacheVault CVPM05

Physical Dimensions

6.600″ x 2.712″

Host Bus Type

x8 lane PCI Express 4.0

Cache Memory

8GB

Internal Ports

8

Data Transfer Rates

12Gb/s SAS and 16GT/s PCIe Gen4 (NVMe) compliant

Devices Supported

SAS/SATA: 240, NVMe: 24

Internal Connectors

1 x8 SFF-8654 (SlimSAS)

MTBF

>3,000,000 hours at 40° C

Operating Temperature

0°C to 55°C

OS

Microsoft Windows, VMware vSphere/ESXi, Red Hat Enterprise Linux, SuSE Linux, Ubuntu Linux, Citrix XenServer, CentOS Linux, Debian Linux, Oracle Enterprise Linux, Fedora, FreeBSD

Regulatory Certifications

Australia/New Zealand (AS/NZS CISPR 22), Canada (ICES -003, Class B), Europe (EN55022/EN55024), Japan (VCCI V-3), Korea (RRA no 2013-24 & 25), RoHS compliant, Safety: EN/IEC/UL 60950, Taiwan (CNS 13438), USA (FCC 47 CFR part 15 Subpart B, class B), WEEE

Warranty

3 years, free technical support, advanced replacement option at broadcom.com/support/warranty/internal-raid-hba

I/O Processor / SAS Controller

SAS3916 12Gb/s SAS Tri-Mode RAID-on-Chip (ROC)
