Hãng sản xuất

Dell

Mã sản phẫm

MB-DELL-T150

Processor

One Intel Xeon E-2300 series processor with up to 8 cores or one Intel Pentium processor with up to 2 cores

Memory

• Four DDR4 DIMM slots, supports UDIMM 128 GB max, speeds up to 3200 MT/s
• Supports unregistered ECC DDR4 DIMMs only
NOTE: For Pentium processor, maximum memory speed supported is 2666 MT/s

Storage controllers

Dell PowerEdge RAID Controller S150

Ports

Front Ports
• 1 x iDRAC Direct (Micro-AB USB) port • 1 x USB 3.0
Rear Ports
• 5 x USB 2.0 • 1 x iDRAC ethernet port • 1 x USB 3.0 • 1 x Serial port • 1 x VGA
Internal Ports
• 1 x USB 3.0 (optional)

PCIe

4 PCIe slots:
• 1x16 Gen4 (x16 connector) full height, half length
• 1x4 Gen4 (x8 connector) full height, half length
• 1x4 Gen3 (x8 connector) full height, half length
• 1x1 Gen3 (x1 connector) full height, half length

Operating System and Hypervisors

• Canonical Ubuntu Server LTS
• Citrix Hypervisor
• Microsoft Windows Server with Hyper-V
• Red Hat Enterprise Linux
• SUSE Linux Enterprise Server
• VMware ESXi (support only from Dec’21) For specifications and interoperability details, see Dell.com/OSsupport

Embedded management

• iDRAC9
• iDRAC Direct
• iDRAC RESTful API with Redfish
• iDRAC Service Module

Embedded NIC

2 x 1 GbE LOM
